Idealpark car lift mod. IP1-HMT V07 with international certification, allows drivers on board during its 11.9 m maximum travel, lifting and/or lowering procedures, for car parking purposes. The plants are equipped with PLC with touch screen display that manages several safety devices for the user ranging from protective photocell barriers that monitor the exact position of the car on the platform, to a system for controlling cable tension. A UPS device allows the descent and the opening of the car lift doors even in the absence of power supply and ensures the driver can exit from the platform.

 The lifts with driver on board can be equipped with remote control to call the platform directly from the car. The system can be fitted with a telephone dialler that allows the driver to contact the rescue centre operating 24 hours a day, in case of emergency

The standard plants are fully galvanised and can be coated in Triplex in a wide range of colours to harmonise them with the surrounding environment.

A wide range of possible finishes and innovative designs allow for the perfect insertion of the system in the architecture of the building and ensure maximum safety and comfort to the user.

The IP1-HMT V07 system is designed to be installed both indoor and outdoor.

Watch the video of IP1-HMT V07!

View the video rendering!
Platform widthfrom 230 to 270 cm
Platform lengthfrom 500 to 560 cm
Capacity Load2.700 kg
Travelup to 11,90 m

IP1-HMT V07
car lifts with on board driver

Enjoy our video!
Download technical documentation
Catalogue car lift with driver on board IP1-HMT V07 Download
Data sheet car lift IP1-HMT V07 Download
DWG car lift IP1-HMT V07 Download
Tender text IP1-HMT V07 Download
EC Type Examination Certificate Download
We are at your complete disposal for a free feasibility study or a quotation. Don't hesitate to contact us!
